| 40' REFRIGERATED (REEFER) CONTAINER |
 |
Outside Dimensions: |
Length |
40'0" ( 12.192 m .) |
Width |
8'0" ( 2.438 m .) |
Height |
8'6" ( 2.591 m .) |
Inside Dimensions: |
Length |
37'11" ( 11.557 m .) |
Width |
7'6" ( 2.286 m .) |
Height |
7'4" ( 2.240 m .) |
Door Opening: |
Width |
7'6" ( 2.286 m .) |
Height |
7'4" ( 2.266 m .) |
Capacity: |
Max.Gross Weight |
67,200 lb ( 30,480 kg .) |
Tare Weight |
9,590 lb ( 4,350 kg .) |
Max. Payload |
57,610 lb ( 26,130 kg .) |
Cubic Capacity |
2,112 cu.ft(59.2 cu. m.) |
Temperature Range |
-25 to + 25 C , +/- 2 C temperature variation |
|
| |
| 40' REFRIGERATED (REEFER) HIGH CUBE CONTAINER |
Outside Dimensions: |
Length |
40'0" ( 12.192 m .) |
Width |
8'0" ( 2.438 m .) |
Height |
9'6" ( 2.896 m .) |
Inside Dimensions: |
Length |
37'11" ( 11.557 m .) |
Width |
7'6" ( 2.286 m .) |
Height |
8'1-3/5" ( 2.505 m .) |
Door Opening: |
Width |
7'6" ( 2.286 m .) |
Height |
8'1-3/5" ( 2.478 m .) |
Capacity: |
Max.Gross Weight |
67,200 lb ( 30,480 kg .) |
Tare Weight |
8,950 lb . ( 4,060 kg .) |
Max. Payload |
58,250 lb ( 26,420 kg .) |
Cubic Capacity |
2,334 cu.ft(66.1 cu. m.) |
Temperature Range |
-25 to + 25 C , +/- 2 C temperature variation |
|
| |
| 20' FLAT RACK |
 |
Outside Dimensions: |
Length |
19'10-1/2" ( 6.058 m .) |
Width |
8'0" ( 2.438 m .) |
Height |
8'6" ( 2.591 m .) |
Capacity: |
Max.Gross Weight |
67,200 lb . ( 30,480 kg .) |
Tare Weight |
6,170 lb . ( 2,800 kg .) |
Max. Payload |
61,030 lb . ( 27,680 kg .) |
|
| |
| 40' FLAT RACK |
Outside Dimensions: |
Length |
38'3-1/8" ( 11.662 m .) |
Width |
7'3-9/16" ( 2.224 m .) |
Height |
6'4-1/2" ( 1.943 m .) |
Capacity: |
Max.Gross Weight |
78,400 lb . ( 35,562 kg .) |
Tare Weight |
11,012 lb . ( 4,995 kg .) |
Max. Payload |
67,388 lb . (30,567) |
